AXIS Q1605-Z H.265 webcam

Excellent image quality and low bandwidth

AXIS q1605-z provides a smooth and very clear HDTV 1080p video at 50/60 frames per second. With its 1/2 "sensor and optimized seeker technology, the camera provides ultra-low illumination imaging performance and low-noise video images in dark environments, reducing motion blur and preserving color information. Zipstream analyzes and optimizes video streams to save bandwidth and storage while maintaining video quality. AXIS q1605-z supports wide dynamic technology as well as seamless switching between light finder and WDR. With the help of CS interface, this camera can support all kinds of lenses. AXIS T91B21 bracket helps to achieve strict cable management.

> HDTV 1080p, up to 50/60 FPS

> 1/2" sensor and seeker technology

> flexible CS interface lens scheme

> supports h. 265

> takes advantage of ansys ZipstreamZipstream Zipstream to save money

> WDR - wide dynamic technology

The camera

Image sensor 1/2 "scans RGB CMOS line by line

Lens zoom lens: 4.4-10mm, F1.2

Horizontal Angle: 96 ° to 43 °

Vertical perspective: 68.7 ° - 32 °

Infrared correction, CS interface lens

Day and night automatic removable infrared filter

Minimum illumination color: 0.02 lux

Black/white: 0.005 lux in the condition of 50 IRE F1.2

The shutter time is 1/125,000 to 1/6s

video

Video compresses h. 264 (mpeg-4 Part 10/AVC) Main and High formats

265 H.

Motion JPEG

HDTV 1080p 25/30 FPS (WDR) : 1920x1080 to 320x240

HDTV 1080p 50/60 FPS (no WDR) : 1920x1080 to

320 x240

Frame rate up to 50/60 FPS (50/60 Hz)

Video streaming provides multiple independently configurable h.264, h.265, and Motion JPEG cells

Type of video stream

Anax Zipstream technology is adopted

Controllable frame speed and bandwidth

VBR/CBR h. 264, h. 265

Multi-view video streams have up to 8 view areas that can be clipped independently

Image set compression, color, brightness, sharpness, contrast, local contrast, white flat

Balance, exposure control, exposure area, WDR - wide dynamic technology: the highest

120 dB (depending on the scene), fine tuning at low illumination, rotation

Turn: 0 ° and 90 °, 180 °, 270 ° (including corridor mode), wen

This and image overlay, privacy mask, image imaging

Translation/tilt/zoom digital PTZ

Uploadable PTZ driver (Pelco D preloaded)

audio

Audio stream bidirectional full duplex

Audio compression AAC LC 8/16/32/48 kHz, g. 711 PCM 8 kHz,

G. 726 ADPCM 8 kHz

Configurable bit rate

Audio input/output external microphone input or line input, line output

network

Secure password protection, IP address filtering, HTTPSa encryption, IEEE 802.1xa

Network access control, digest authentication, user access logs

Supported protocols IPv4/v6, HTTP, HTTPSa, SSL/TLSa, QoS Layer

3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour,

UPnP ?, SNMP v1 / v2c/v3 (MIB - II), DNS, DynDNS,

NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP,

RTCP, ICMP, DHCP, ARP, SOCKS, SSH

System integration

Application programming

interface

Open API for software integration, including VAPIX ? and

AXIS camera application platform, specifications in www.axis.com

ONVIF ? Profile S and ONVIF ? Profile G, www.onvif.org

The specifications of the

Intelligent analysis AXIS Video Motion Detection 4. Active tamper Detection alarm and sound Detection

Frequency detection

AXIS camera application platform is supported to install third-party applications, please

See www.axis.com/acap

Event trigger analysis, front-end storage events, external input, audio level, scheduled time

Event action file upload: FTP, SFTP, HTTP, HTTPS, network sharing and

E-mail

Notifications: E-mail, HTTP, HTTPS, and TCP

External output activation

Record video to the front end to store and play audio clips

Video buffer before and after alarm

PTZ preset, round trip, overlay text

Day/night switching, state LED activation

WDR mode

Send SNMP traps

Data flow event data

Built-in install help pixel counter

conventional

The shell metal

Top cover: grey RAL 9006

Case: black - NCS S 9000-n

Sustainability without PVC

Memory 512 MB RAM, 256 MB flash memory

Power supply 12V DC/ 24V AC or Ethernet power supply (PoE)

IEEE 802.3af Class 2, Max. 3W

Interface RJ45 10base-t / 100base-tx PoE interface

I/O: 4-pin 2.5mm terminal for two configurable inputs/outputs

12V DC/24VAC power interface

3.5mm microphone/line input, 3.5mm line compound output, support

Video output (audio/video composite output line is required)

RS485/RS422 full duplex interface

Aperture control line interface

Ground screw post

Storage support microSD/microSDHC/microSDXC card

Support for recording to network additional storage (NAS)

See www.axis.com for recommendations on SD CARDS and NAS

Working conditions at 0 ° C to 55 ° C

Humidity 10-85% RH (non-condensing)

Storage conditions and 40 ° C to 65 ° C

Certified inspection report

Dimensions 175 X 77 X 49 mm (length X width X height)

Weight 380 grams,

Includes accessory connector kit, installation guide, Windows decoder single user license

AXIS T91B21 stent

Optional accessory audio - video compound output line

Optional ansons shield and lens
